Chapter 2

Hardware Setup

Cable Connections

To set up your installation, refer to the installation diagram on the following

page (the numbers in the diagram on page 11 correspond to the steps below),

and do the following:

1. Plug the USB keyboard and USB mouse into the USB console ports

located on the unit’s rear panel.

2. Plug the console monitor into the DisplayPort and/or HDMI port located

on the unit’s rear panel and power on the monitor(s). For multiple monitor

setups, see Display Modes, on page 16.

3. Plug the main microphone and speakers into the console microphone and

speaker jacks located on the unit’s front panel. The microphone and

speakers plugged into these ports have priority over those in the rear panel.

4. (Optional) Plug your secondary microphone and speakers into the console

audio ports located on the unit’s rear panel.

1. Important safety information regarding the placement of this

device is provided on page 43. Please review it before

proceeding.

2. To prevent damage to your installation from power surges or

static electricity. It is important that all connected devices are

properly grounded.

3. Make sure that power to all the devices you will be installing has

been turned off. You must unplug the power cords of any

computers that have the Keyboard Power On function.

4. Please operate the device with caution when under high

environmental temperatures, as the surface of the device may

become overheated under such conditions. For instance, the

surface temperature of the device may reach 70 °C (158 °F) or

higher when the environmental temperature reaches close 50 °C

(122 °F).
