CS1922M / CS1924M User Manual
10
5. Using the cables provided with this package, plug the DisplayPort, USB
3.0, microphone, and speaker connectors into their corresponding sockets
in the KVM Port section of the switch.
Note: Verify that all the plugs are in the same KVM Port sockets (all in
port 1, all in port 2, etc.) Each socket is marked with an appropriate
icon to indicate its function.
6. At the other end of the cable set, plug the DisplayPort, USB 3.0,
microphone, and speaker connectors into their respective ports on the
computer.
7. (Optional) Plug USB peripherals into the USB 3.0 ports located on the
unit’s front and rear panel.
8. (Optional) Connect an RJ11-to-DB9 cable from the unit’s serial port to a
computer’s serial port for RS-232 control.
Note: The RJ11-to-DB9 cable is sold separately. Contact your ATEN
dealer for product information.
9. Plug the power adapter (provided with this package) into the unit’s power
jack and then plug the other end into an AC power source.
10. Power on the computers.
Note: By default, the CS1922M / CS1924M switches to the first
computer that is powered on.
We recommend that the total video cable length from the PC to
the console monitor cannot exceed 3 meters.
Choosing high quality video cable ensures 4K UHD (3840x2160
@ 60 Hz) or 4K DCI (4096x2160 @ 60Hz) resolutions can be
achieved.
Make sure the computers and devices that the CS1922M /
CS1924M connects to are also properly grounded.
