Chapter 4. Hotkey Operation
31
Alternative Manual Port Selection
To toggle between the default and the alternative front panel pushbutton
manual port selection settings, do the following:
1. Invoke HSM (see page 27).
2. Press [S].
This procedure is a toggle. Repeat to revert to the original setting. See
Alternative Manual Port Selection Settings, page 15, for more
information.
Mouse Emulation
To toggle between mouse emulation enabled and disabled, do the following:
1. Invoke HSM (see page 27
).
2. Press [M].
This procedure is a toggle. Repeat to revert to the original setting
Mouse Port Switching
Mouse Port Switching allows you to use the mouse wheel button (clicked
twice) to switch ports. For Mouse Port Switching to work, Mouse Emulation
(above) must be enabled. To toggle between mouse port switching enabled and
disabled, do the following:
1. Invoke HSM (see page 27
).
2. Press [W].
This procedure is a toggle. Repeat to revert to the original setting.
Note: This feature is only supported by USB 3-key scroll wheel mice. The
default setting is disabled. This feature is only supported when
mouse emulation is also enabled. See Mouse Emulation, above.
