Appendix
47
Specifications
Function CS1922M CS1924M
Connections Computer 2 4
Console 1
Port Selection Pushbuttons, Hotkey, Mouse*, RS-232 Commands
Connectors Console
Ports
Keyboard 1 x USB Type A
Video 1 x DisplayPort
1 x HDMI
Mouse 1 x USB Type A
Speakers 1 x 3.5 mm Mini Stereo Jack (Green; Front)
1 x 3.5 mm Mini Stereo Jack (Green; Rear)
Mic 1 x 3.5 mm Mini Stereo Jack (Pink; Front)
1 x 3.5 mm Mini Stereo Jack (Pink; Rear)
KVM Ports KB /
Mouse
2 x USB 3.1 Gen 1 Type B 4 x USB 3.1 Gen 1 Type B
Video 2 x DisplayPort 4 x DisplayPort
Speakers 2 x 3.5 mm Mini Stereo
Jack (Green)
4 x 3.5 mm Mini Stereo
Jack (Green)
Mic 2 x 3.5 mm Mini Stereo
Jack (Pink)
4 x 3.5 mm Mini Stereo
Jack (Pink)
USB Hub 1 x USB 3.1 Gen 1 Type A (Front)
1 x USB 3.1 Gen 1 Type A (Rear)
Serial 1 x RJ-11 Female
Power 1 x DC Jack
Switches Selected 2 x Pushbutton 4 x Pushbutton
LEDs On Line / Selected 2 (Orange) 4 (Orange)
USB Link 2 (Green) 4 (Green)
Emulation Keyboard / Mouse USB
Video 4096 x 2160 @ 60 Hz (4K DCI)
Scan Interval 1–99 secs. (5 secs. default)
Power Consumption DC5V:4.09W:62BTU DC5V:4.89W:66BTU
Environment Operating Temp. 0–50º C
Storage Temp. -20–60º C
Humidity 0–80% RH, Non-condensing
