CS1922M / CS1924M User Manual

Example 1

To bring the KVM, USB hub, and audio focus from port 1 to port 2, do the

following:

1. Press [Scroll Lock] twice.

2. Press [Enter].

Example 2

To bring the KVM focus from port 1 to port 2, do the following:

1. Press [Scroll Lock] twice.

2. Press [K].

3. Press [Enter].

Example 3

To bring the USB hub focus from port 1 to port 2, do the following:

1. Press [Scroll Lock] twice.

2. Press [U].

3. Press [Enter].

Example 4

To bring the audio focus from port 1 to port 2, do the following:

1. Press [Scroll Lock] twice.

2. Press [S].

3. Press [Enter].
