Aten CN8600 [153/167] Certificate trusted

Appendix

139

7. Next, click Finish to complete the installation; then click OK to close the

dialog box.

Certificate Trusted

The certificate is now trusted:

When you click View Certificate, you can see that the red and white X logo is

no longer present – further indication that the certificate is trusted:
