Aten CN8600 [28/167] Power on the cn8600 then power on the server kvm switch

CN8600 User Manual

Note: Dual power operation is optional — the second power source is for

back-up; a second power adapter requires a separate purchase

11. Power on the CN8600, then power on the server/KVM switch.

Note: For safety purposes, we suggest you ground the switch using a

grounding wire.

Over-IP PDU

Over-IP devices

Network

DVI KVM Cable Connection
