Aten CN8600 [20/167] Operating systems
![Aten CN8600 [20/167] Operating systems](/views2/1977342/page20/bg14.png)
CN8600 User Manual
6
Cat 5e/6 or higher Ethernet cable (not provided with this package) should
be used to connect the CN8600 to the LAN, WAN, or Internet.
Video
Only the following non-interlaced video signals are supported:
Operating Systems
Supported operating systems for remote user computers that logging into
the CN8600 include Windows 2000 or later, and other systems capable of
running Sun's Java Runtime Environment (JRE) 6, Update 3, or later
(Linux, Mac, Sun, etc.).
Supported operating systems for servers that connect to the CN8600 are
shown in the table below:
Resolution Refresh Rates
640 x 480 60, 72, 75
720 x 400 70
800 x 600 56, 60, 72, 75, 85
1024 x 768 60, 70, 75, 85
1152 x 864 60, 70, 75, 85
1280 x 720 60
1280 x 1024 60, 70, 75, 85
1600 x 1200 60
1680 x 1050 60
1920 x 1200 60
OS Version
Windows 2000 or later
Linux RedHat 7.1 or later
Fedora Core 5 or later
SuSE 9.0 or later
Mandriva (Mandrake) 9.0 or later
UNIX AIX 4.3 or later
FreeBSD 3.51 or later
Sun Solaris 8 or later
