CN8600 User Manual
16
Note: The Security Alert screen’s appearance varies depending on the
browser version.
The CN8600 login page appears:
3. Provide a valid Username and Password (set by the CN8600
administrator), then click Login to continue.
Note: 1. If you are the administrator and are logging in for the first time,
use the default Username: administrator; and the default
Password: password. For security purposes, the system will
prompt you to change the login password. The password must be
different from your login password.
2. If you supplied an invalid login, the authentication routine will
return this message: Invalid Username or Password. Please try
again. If you see this message, log in again being careful with the
Username and Password.
The main page appears after logging in successfully.
