ADJ Duo Scan RG [7/10] This function will allow you to test the pan tilt functions
![ADJ Duo Scan RG [7/10] This function will allow you to test the pan tilt functions](/views2/1990711/page7/bg7.png)
©American DJ® - www.americandj.com - Duo Scan RG Instruction Manual Page 14©American DJ® - www.americandj.com - Duo Scan RG Instruction Manual Page 13
3. Press ENTER to conrm, and then press and hold the MENU button
for at least 3 seconds.
SOUN - Sound Active mode.
1. Press the MENU button until “SOUN” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or DOWN
buttons to select “ON” to activate sound active mode, or “OFF” to
deactivate sound active mode.
3. Press ENTER and then hold MENU for at least 2-3 seconds to
conm.
SOSE - Sound sensitivity control.
1. Press the MENU button until “SOSE” is displayed, press ENTER.
2. The display will show a number between 0-100. Press the UP or
DOWN buttons to adjust the sound sensitivity. 0 being the least sen-
sitive and 100 the most sensitive.
3. Press the ENTER, and then press and hold the MENU button for at
least 3 seconds to conrm.
BLND - Blackout or Stand by mode.
1. Press the MENU button until “BLND” is displayed, press ENTER.
Either Yes or No will be displayed.
2. To activate Blackout tap the UP or DOWN buttons until “Yes” is
displayed, press ENTER to conm. The xture will now be in Blackout
mode. To deactivate Blackout mode, select “No” and press Enter.
LED - With this function you can have the LED display
turn off after 10 seconds.
1. Press the MENU button until “LED” is displayed, press ENTER.
2. The display will show either “ON” or “OFF”. Press the UP or DOWN
buttons to select “ON” to keep the LED display on at all times, or
“OFF” to switch to have the LED display switch off after 10 seconds.
3. Press ENTER and then hold MENU for at least 2-3 seconds to
conm.
DISP - This function will “ip” the LED display 180º.
1. Press the MENU button until “DISP” is displayed, press ENTER.
2. Press ENTER to “ip” the display. Press ENTER to “ip” it again.
Press ENTER when you have made your desired setup.
TEST - This function will allow you to test the pan & tilt
functions.
1. Press the MENU button until “TEST” is displayed, press ENTER.
2. Either “PAN”, “TILT” or “P T” will be displayed. Use the UP or DOWN
buttons to scroll to the function you would like to test and press
ENTER. The function will now run a self test.
FHRS - With this function you can display the running time
of the xture.
1. Press the MENU button until “FHRS” is displayed, press ENTER.
2. The display shows the running time of the unit. Press MENU to
exit.
VER - With this function you can display the version soft-
ware of the unit.
1. Press the MENU button until “VER” is displayed, press ENTER.
2. The display will now display the version of software. Press MENU
to exit.
RSET - Use this function to reset the unit.
1. Press the MENU button until “RSET” is displayed, press ENTER.
2. The xture will now reset.
Duo Scan RG System Menu Duo Scan RG System Menu
