Tesla TT27TP61S-0932IAWUV [51/64] Indoor unit installation

ENG

This table is only for reference, the installation shall meet the requirements of local laws

and regulations.

NOTE

Maximum Operating

Current of Air

Conditioner (A)

Minimum Wire Cross-

sectional Area (mm

)

Speciﬁcation of Socket

or Switch (A)

Fuse Speciﬁcation (A)

≤ 8 0.75 10 20

> 8 and ≤10 1.0 10 20

> 10 and ≤15 1.5 16 32

> 15 and ≤24 2.5 25 32

> 24 and ≤28 4.0 32 64

> 28 and ≤32 6.0 40 64

Dedicated Distribution Device and Wire for Air Conditioner

Step1: Select Installation location

1. Ensure the installation complies with the installation minimum dimensions (deﬁned below) and meets the

minimum and maximum connecting piping length and maximum change in elevation as deﬁned in the

System Requirements section.

2. Air inlet and outlet will be clear of obstructions, ensuring proper airﬂow throughout the room.

3. Condensate can be easily and safely drained.

4. All connections can be easily made to outdoor unit.

5. Indoor unit is out of reach of children.

6. A mounting wall strong enough to withstand four times the full weight and vibration of the unit.

7. Filter can be easily accessed for cleaning.

8. Leave enough free space to allow access for routine maintenance.

9. Install at least 10 ft. (3 m) away from the antenna of TV set or radio. Operation of the air conditioner may

interfere with radio or TV reception in areas where reception is weak. An ampliﬁer may be required for the

affected device.

10. Do not install in a laundry room or by a swimming pool due to the corrosive environment.

INDOOR UNIT INSTALLATION
