ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 25ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 24
Vizi Hybrid 16RX System Menu
to return to the main menu.
Tilt Inverse - With this function, you can reverse the Tilt movement.
1. Access the main menu, and press the UP or DOWN buttons so
that “Fixture Settings” is higlighted, then press ENTER.
2. Press the UP or DOWN buttons until “Tilt Inverse” is displayed,
and press ENTER. The current setting will now be displayed.
3. Use the UP or DOWN buttons to switch between “YES” and “NO”.
Selecting “YES” will activate tilt inverse, “NO” will deactivate the
function.
4. Press ENTER to conrm your selection or press the MENU button
to return to the main menu.
P/T Feedback - With this function, you have the pan and tilts postion
feedback while out of step or not feedback while out of step.
1. Access the main menu, and press the UP or DOWN buttons so
that “Fixture Settings” is higlighted, then press ENTER.
2. Press the UP or DOWN buttons until “P/T Feedback” is displayed,
and press ENTER. The current setting will now be displayed.
3. Use the UP or DOWN buttons to switch between “YES” and “NO”.
Selecting “YES” will activate feedback, “NO” will deactivate the func-
tion.
4. Press ENTER to conrm your selection or press the MENU button
to return to the main menu.
BLO. P/T Moving - With this function, the xture will blackout with
pan and tilt movement.
1. Access the main menu, and press the UP or DOWN buttons so
that “Fixture Settings” is higlighted, then press ENTER.
2. Press the UP or DOWN buttons until “BLO. P/T Moving” is dis-
played, and press ENTER. The current setting will now be displayed.
3. Use the UP or DOWN buttons to switch between “YES” and “NO”.
Selecting “YES” will activate the blackout function, “NO” will deacti-
Vizi Hybrid 16RX System Menu
vate the function.
4. Press ENTER to conrm your selection or press the MENU button
to return to the main menu.
BLO. Color Change - With this function, the xture will blackout with
while changing colors.
1. Access the main menu, and press the UP or DOWN buttons so
that “Fixture Settings” is higlighted, then press ENTER.
2. Press the UP or DOWN buttons until “BLO. Color Change” is dis-
played, and press ENTER. The current setting will now be displayed.
3. Use the UP or DOWN buttons to switch between “YES” and “NO”.
Selecting “YES” will activate the blackout function, “NO” will deacti-
vate the function.
4. Press ENTER to conrm your selection or press the MENU button
to return to the main menu.
BLO. Gobo Change - With this function, the xture will blackout with
while changing gobos.
1. Access the main menu, and press the UP or DOWN buttons so
that “Fixture Settings” is higlighted, then press ENTER.
2. Press the UP or DOWN buttons until “BLO. Gobo Change” is dis-
played, and press ENTER. The current setting will now be displayed.
3. Use the UP or DOWN buttons to switch between “YES” and “NO”.
Selecting “YES” will activate the blackout function, “NO” will deacti-
vate the function.
4. Press ENTER to conrm your selection or press the MENU button
to return to the main menu.
LAMP SETTINGS -
Lamp On/O - With this function, you can switch the lamp On or O
from the control board.
1. Access the main menu, and press the UP or DOWN buttons so
that “Lamp Settings” is higlighted, then press ENTER.
