ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 23ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 22
2. Press the UP or DOWN buttons until “DMX State” is displayed,
and press ENTER. Use the UP and DOWN buttons to switch between
the two modes; Blackout or Hold. Press the ENTER button to make
your selection.
• HOLD - If the DMX signal is lost the xture will stay in the last DMX
setting. If power is applied and this mode is set, the unit will automati-
cally go into the last DMX set up.
• BLACKOUT - If the DMX signal is lost or interrupted, the unit will
automatically go into stand by mode.
3. Press the MENU button to return to the main menu.
DMX Value - This function will allow you to see the DMX value of
each DMX channel that is currently being used at the time.
1. Access the main menu, and press the UP or DOWN buttons so
that “DMX Settings” is highlighted, then press ENTER.
2. Press the UP or DOWN buttons until “DMX Value” is displayed,
and press ENTER.
3. A DMX Channel will be displayed. Example: Prism, Color Wheel,
Gobo Wheel, etc... Press ENTER when you nd the DMX channel that
you would like to check. When you press ENTER the DMX value of
that channel will displayed.
4. Press the MENU button to exit and return to the main menu.
FIXTURE SETTINGS -
Pan Inverse - With this function, you can reverse the Pan movement.
1. Access the main menu, and press the UP or DOWN buttons so
that “Fixture Settings” is higlighted, then press ENTER.
2. Press the UP or DOWN buttons until “Pan Inverse” is displayed,
and press ENTER. The current setting will now be displayed.
3. Use the UP or DOWN buttons to switch between “YES” and “NO”.
Selecting “YES” will activate pan inverse, “NO” will deactivate the
function.
4. Press ENTER to conrm your selection or press the MENU button
Vizi Hybrid 16RX System Menu Vizi Hybrid 16RX System Menu
System Menu: When making adjustments press ENTER to
conrm your setup then press and hold the MENU button
for at least 3 seconds. To exit without making any adjust-
ments press the MENU button. The display will lock after 30
seconds, press the MENU button for 3 seconds to unlock.
DMX SETTINGS -
DMX Address - With this function, you can adjust the desired DMX-
address via the Control Board.
1. Access the main menu, and press the UP or DOWN buttons so
that “DMX Settings” is higlighted, then press ENTER.
2. Press the UP or DOWN buttons until “DMX Address” is displayed,
and press ENTER. The current DMX address will now be displayed.
3. Use the UP or DOWN buttons to adjust the DMX address.
4. Press ENTER to conrm or press MENU button to return to the
main menu.
DMX Channel Mode - With this function, you can see the how many
DMX channels the xture has.
1. Access the main menu, and press the UP or DOWN buttons so
that “DMX Settings” is higlighted, then press ENTER.
2. Press the UP or DOWN buttons until “DMX Channel Mode” is
displayed, and press ENTER. The number of DMX channels will now
be displayed.
3. Press the MENU button to return to the main menu.
DMX State -
This mode can be used as a precaution mode, that
in case the DMX signal is lost, interrupted, or power is lost, the
operating mode chosen in this setup is the running mode the
xture will go into when the DMX signal is lost. You can also
set this as the running mode you would like the unit to return to
when power is applied.
1. Access the main menu, and press the UP or DOWN buttons so
that “DMX Settings” is higlighted, then press ENTER.
