Unpacking: Thank you for purchasing the Vizi Hybrid 16RX by ADJ
Products, LLC®. Every Vizi Hybrid 16RX has been thoroughly tested
and has been shipped in perfect operating condition. Carefully check
the shipping carton for damage that may have occurred during ship-
ping. If the carton appears to be damaged, carefully inspect your x-
ture for any damage and be sure all equipment necessary to operate
the unit has arrived intact. In the event damage has been found or parts
are missing, please contact our toll free customer support number for
further instructions. Please do not return this unit to your dealer with-
out contacting customer support rst.
Introduction: The Vizi Hybrid 16RX is a DMX intelligent, moving head
fixture. The Vizi Hybrid 16RX is a 19 channel DMX unit. This fixture is a
DMX controlled unit. For best results use fog or special effects smoke
to enhance the beams projections.
During the initial start-up or use of this product a light smoke or
smell may arise from the unit. This is a normal process and is
cause by the heat associated with the lamp.
Customer Support: ADJ Products, LLC® provides a toll free cus-
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.adj.com for any comments or
suggestions. Service Hours are Monday through Friday 8:00 a.m. to
4:30 p.m. Pacic Standard Time.
Voice: (800) 322-6337
Fax: (323) 582-2610
E-mail: support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning! To prevent or reduce the risk of electrical shock or re, do
not expose this unit to rain or moisture.
Warning! This may cause severe eye damage. Avoid looking
directly into the light source at all times!
WARNING! CAUTION! FIRE HAZARD! DUE TO THE EXTREME
HEAT CAUSED BY THIS LAMP, THE MINIMUM DISTANCE TO
LIGHTED OBJECTS IS 12 METERS (40FT).
Vizi Hybrid 16RX General Information
ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 2 ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 3
Vizi Hybrid 16RX
Table of Contents
Unpacking......................................................................3
Introduction....................................................................3
Customer Support......................................................................3
Safety Precautions......................................................................4
Features.........................................................................5
Handling Precautions..................................................................6
Registration......................................................................6
Important Discharge Lamp Warnings.........................................7
Fire Warning................................................................................7
Mounting.........................................................................8-9
CAD Drawing.............................................................................10
Base Layout..............................................................................11
DMX Set-Up.........................................................................12-14
DMX Control..............................................................................15
DMX Traits............................................................................16-20
System Menu.......................................................................21-31
Oset Menu.........................................................................32-35
Error Information..................................................................36-37
Fuse Replacement....................................................................38
Lamp Replacement..............................................................38-40
Photometric Chart.....................................................................38
Changing the Glass Gobo.........................................................41
Cleaning..................................................................42
Trouble Shooting.......................................................................42
Warranty.........................................................................43
Specifications....................................................................46
Please see page 7 for important lamp instructions!
Warning this xture can start a re, please see page 7 for precau-
tions.
