For Your Own Personal Safety, Please Read and Understand This
Manual Completely Before You Attempt To Install Or Operate
This Unit!
• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Be sure that the local power outlet match that of the required volt-
age for your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken.
• Do not attempt to remove or break o the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 40 for cleaning details.
• Heat -This fixture should be situated away from heat sources such
as radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. Objects have fallen, or liquid has been spilled into the appliance.
B. The appliance has been exposed to rain or water.
C. The appliance does not appear to operate normally or exhibits a
marked change in performance.
Vizi Hybrid 16RX Safety Precautions
ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 4 ADJ Products, LLC - www.adj.com - Vizi Hybrid 16RX Instruction Manual Page 5
• Philips® Platinum 16R Discharge Lamp
• Micro-Stepping Motors for Smooth Color and Gobo Transitions
• DMX-512 Protocol Compatible (19 DMX Channels)
• 3/5-Pin XLR In/Out
• Independent Gobo and Color Wheels
• 2 Seperate Gobo Wheels
16 Static Fixed Gobos + Spot & Frost
12 Colored Glass Rotating Gobos + Spot
• 14 Colors, Plus White and Split Colors
• 6 Facet Prism & 8 Facet Prism with Prism Morphing
• Prism Rotation
• Frost Filter
• Strobe Effect
• Motorized Focus
• Motorized Zoom
• 3-32 Degree Beam Angle
• 360˚ Pan Movement Standard (540˚ Degree Optional)
• 270˚ Tilt Movement
• Pan/Tilt Invert
• Pan/Tilt Speed Adjustment
• Digital Display for Address and Function Setting
Vizi Hybrid 16RX Features
