ADJ Products, LLC - www.adj.com - Inno Pocket Spot LZR Instruction Manual Page 23ADJ Products, LLC - www.adj.com - Inno Pocket Spot LZR Instruction Manual Page 22
The UC IR (sold separately) infrared remote gives you control of various
functions (See below). To control the fixture you must aim the remote at the
front of the fixture and be no more than 30 feet away.
The Inno Pocket Spot LZR comes with the Airstream IR remote transmit-
ter. The transmitter plugs into the headphone jack of your iOS phone or
tablet. To control your IR fixture you must raise the volume to the maximum
on your iOS phone or table and aim the transmitter at the front of the fixture
and be no more than 15 feet away. After you have purchased the Airstream
IR transmitters, the app is a free download from the app store for your iOS
phone or tablet. The app comes with 3 pages of control depending on the
IR fixture you are using. Please see below for IR functions including the cor-
responding app page.
Works with App pages 1 & 2. Page 2 is used to adjust Pan/Tilt. See
Show 0.
STAND BY - Pressing this button will blackout the fixture.
FULL ON - Hold this button down to fully light up the unit. When you let the
button go, the unit will return to its previous state.
FADE/GOBO - Press this button to enter Gobo mode. Use the 1-9 buttons
to select your desired gobo.
“DIMMER +” and “DIMMER -” - Use these buttons to adjust the output in-
tensity and to adjust the strobe speed.
STROBE - This button will activate the strobe effect. You can control the
flash rate by pressing the “DIMMER +” and “DIMMER -” buttons. If you
press and hold this button the unit will begin to strobe.
COLOR -
Press this button to enter Dimmer mode. Use the 1-9 buttons to
select your desired color.
1-9 - When in Gobo mode, Color mode, or Show mode, these buttons will
allow you to select a gobo, color, or show.
SOUND ON & OFF - These buttons activate and deactivate the sound ac-
tive mode.
SHOW 0 - Press this button once to enter Show mode. Use buttons 1-4 to
select your desired show. To enter Pan/Tilt adjustment mode, press and
hold this button for more then 3 seconds. Use buttons 2 & 8 to adjust Tilt.
Use buttons 4 & 6 to adjust Pan. Press button 5 center the Pan/Tilt. Press
and hold this button again to cancel this mode. App page 2 is used to ad-
just Pan and Tilt.
Inno Pocket Spot LZR Remote Operation
Inno Pocket Spot LZR Master-Slave Set Up
Master-Slave Operation This function will allow you to link up to
16 units together and operate without a controller. In a Master-Slave
set up one unit will act as the controlling unit and the others will react
to the controlling units programs. Any unit can act as a Master or as a
Slave.
1. Using approved DMX data cables, daisy chain your units togeth-
er via the XLR connector on the rear of the units. Remember the
Male XLR connector is the input and the Female XLR connector
is the output. The rst unit in the chain (master) will use the female
XLR connector only - The last unit in the chain will use the male
XLR connector only. For longer cable runs we suggest a termina-
tor at the last fixture.
2. On the master unit press the MENU button until “SLND” is dis-
played, and press ENTER. Use the UP and DOWN buttons to
scroll to the “MAST” setting and press ENTER.
3. After setting the master unit, find your desired operating mode.
4. On the slave units press the MENU button until “SLND” is dis-
played, and press ENTER. Choose either “SL 1” or “SL 2” and
press ENTER.
5. The slave units will now follow the master unit.
NoTE: In a Master/Slave conguration you can set one xture to
Master and then set the next xture to “SL 2”, the xtures will now
have contrast movement to each other.
This feature lets you instantly blackout the laser eect. Have the key
inserted into the keyhole at all times. To activate the laser blackout
feature turn it to the “O” position. To reactivate the laser turn the key
to the “On” position.
Inno Pocket Spot LZR Laser Blackout (Europe Only)
