• To reduce the risk of electrical shock or re, do not expose this unit
rain or moisture
• Do not spill water or other liquids into or on to your unit.
• Do not attempt to operate this unit if the power cord has been
frayed or broken.
• Do not attempt to remove or break o the ground prong from
the electrical cord. This prong is used to reduce the risk of electrical
shock and re in case of an internal short.
• Disconnect from main power before making any type of connection.
• Do not remove the cover under any conditions. There are no user
serviceable parts inside.
• Never operate this unit when it’s cover is removed.
• Always be sure to mount this unit in an area that will allow proper
ventilation. Allow about 6” (15cm) between this device and a wall.
• Do not attempt to operate this unit, if it becomes damaged.
• This unit is intended for indoor use only, use of this product out-
doors voids all warranties.
• Always mount this unit in safe and stable matter.
• Power-supply cords should be routed so that they are not likely to
be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience recep-
tacles, and the point where they exit from the appliance.
• Cleaning -The fixture should be cleaned only as recommended by
the manufacturer. See page 33 for cleaning details.
• Heat -This fixture should be situated away from heat sources such
as radiators, heat registers, stoves, or other appliances (including
amplifiers) that produce heat.
• The fixture should be serviced by qualified service personnel when:
A. Objects have fallen, or liquid has been spilled into the appliance.
B. The appliance has been exposed to rain or water.
C. The appliance does not appear to operate normally or exhibits
a marked change in performance.
Inno Pocket Spot LZR Safety Precautions
ADJ Products, LLC - www.adj.com - Inno Pocket Spot LZR Instruction Manual Page 5ADJ Products, LLC - www.adj.com - Inno Pocket Spot LZR Instruction Manual Page 4
DANGER
VISIBLE LASER RADIATION
-AVOID DIRECT EYE EXPOSURE
LASER DIODE
WAVELENGTH : 635~650 nm
Max Output : <4.9mW
Class IIIa Laser Product
!
!
NON-INTERLOCKED HOUSING WARNING
The Inno Pocket Spot LZR contains high power laser devices inter-
nally. Do not open the laser housing, due to the potential exposure
to unsafe levels of laser radiation. The laser power levels, if the unit is
opened, can cause instant blindness, skin burns and res.
STOP AND READ ALL LASER SAFETY DATA
OPERATION INSTRUCTIONS AND LASER SAFETY
The light source emitted from this product can potentially cause eye
injury if not set up and used properly. The light source emitted from a
laser is very dierent from any other light sources with which you may
be aware of. Laser light is thousands of times more concentrated
than any light from any other kind of light source. This concentration
of light can cause instant eye injuries, primarily by burning the retina
(the back of your eyeball contatining cells that are sensitive to light).
Even if you cannot feel “heat” from a laser beam, it can still poten-
tially injure or blind you or your audience. Even very small amounts
of laser beam light are potentially hazardous even at long distances.
Laser eye injuries can be sustained faster than you can blink.
Do not think that because this laser splits the laser beam into hun-
dreds of beams and that the laser beam is scanned out in high
speed, that an individual laser beam is safe for eye exposure. This
laser uses dozens of milliwatts of laser power (Class 3B levels inter-
nally) before it splits into multiple beams (Class 3R levels). Many of
the individual beams are potentially hazardous to the eyes.
Do not that because the laser light is moving, it is safe. This is not
true. Nor, do the laser beams always move. Since eye injuries can
occur instantly, it is critical to prevent even the smallest possibility of
any direct eye exposure. In the laser safety regulation, it is not legal
to aim Class 3R lasers in areas which people can get exposed. This
is true even if it is aimed below people’s faces, such as on a dance
oor.
Do not operate the laser without rst reading and understanding
all safety and technical data in this manual.
Always set up and install all laser eects so that all laser light is at
least 3 meters (9.8 feet) above the oor on which people can stand.
Inno Pocket Spot LZR
Laser Warnings and Safety
Содержание
- Inno pocket spot lzr 1
- User instructions 1
- Caution 2
- Customer support 2
- Introduction 2
- Unpacking 2
- Warning 2
- Danger 3
- Stop and read all laser safety data operation instructions and laser safety 3
- European version 4
- Us version 4
- Notice the suitable enviromental temperature for this light ing fixture is between 25 c to 45 c do not place this lighting fixture in an enviroment where the temperatures are under or above the temperatures stated above this will allow the fixture to run at its best and help prolong the fixture life 5
- Screw one clamp via a m12 screw and nut to the included bracket attach the bracket using the included screws to the bottom of the inno pocket spot lzr attach the eyehole screw to the bottom of the base and pull the safety cable through the screw and over the trussing system or a safe fixation spot insert the end in the carabine and tighten the safety screw 5
- Dmx 512 6
- Notice 6
- Power supply 6
- Special note line termination 6
- Conductor 5 pin xlr male in 3 pin xlr female out 7
- Inno pocket spot lzr dmx set up 7
- Inno pocket spot lzr front rear layout 7
- Pin xlr dmx connectors 7
- Pin xlr to 5 pin xlr conversion 7
- Some manufactures use 5 pin dmx 512 data cables for data transmission in place of 3 pin 5 pin dmx fixtures may be implemented in a 3 pin dmx line when inserting stan dard 5 pin data cables in to a 3 pin line a cable adaptor must be used these adaptors are readily available at most electric stores the chart below details a proper cable conversion 7
- Dmx address setting 8
- Show modes 0 4 factory programs show mode can run with or without sound active mode active 8
- System menu when making adjustments press enter to confirm your setup then press and hold the menu button for at least 3 seconds to exit without making any adjust ments press the menu button the display will lock after 30 seconds press the menu button for 3 seconds to unlock 8
- This will let select your desired dmx channel mode 8
- This will let you set unit as a master or slave in a master slave configuration 8
- In this mode you can adjust the sound sensitiv ity 9
- Pan inversion 9
- Sound active mode 9
- This mode can be used as a precaution mode that in case the dmx signal is lost interrupted or power is lost the operating mode chosen in the setup is the running mode the fixture will go into when the dmx signal is lost you can also set this as the operating mode you would like the unit to return to when power is applied 9
- This will let select your desired dimmer curve 9
- Tilt inversion 9
- Adjustment of the pan position 10
- This function will reverse the display 180º 10
- This function will run a self test program 10
- This function will show you current running tem perature 10
- Use this function to display the software version of the unit 10
- Use this function to reset the unit 10
- With this function you can display the running time of the unit 10
- With this function you can have the led display turn off after 10 seconds 10
- Adjustment for the color wheel 11
- Adjustment of the gobo wheel 11
- Adjustment of the tilt position 11
- Show mode 11
- Sound active mode 11
- Universal dmx control 11
- Inno pocket spot lzr laser blackout europe only 12
- Inno pocket spot lzr master slave set up 12
- Inno pocket spot lzr remote operation 12
- Master slave operation 12
- This feature lets you instantly blackout the laser effect have the key inserted into the keyhole at all times to activate the laser blackout feature turn it to the off position to reactivate the laser turn the key to the on position 12
- This function will allow you to link up to 16 units together and operate without a controller in a master slave set up one unit will act as the controlling unit and the others will react to the controlling units programs any unit can act as a master or as a slave 1 using approved dmx data cables daisy chain your units togeth er via the xlr connector on the rear of the units remember the male xlr connector is the input and the female xlr connector is the output the first unit in the chain master will use the female xlr connector only the last unit in the chain will use the male xlr connector only for longer cable runs we suggest a termina tor at the last fixture 2 on the master unit press the menu button until slnd is dis played and press enter use the up and down buttons to scroll to the mast setting and press enter 3 after setting the master unit find your desired operating mode 4 on the slave units press the menu button until slnd is dis played and press enter choose either sl 1 or s 12
- Channel value function 13
- Channel value function 14
- Channel value function 15
- Channel value function 16
- Channel value function 17
- Adj products llc www adj com inno pocket spot lzr instruction manual page 36 adj products llc www adj com inno pocket spot lzr instruction manual page 37 19
- Inno pocket spot lzr notes 19
- Inno pocket spot lzr warranty 19
- A d j supply europe b v junostraat 2 6468 ew kerkrade netherlands service adjgroup eu www adj eu tel 31 45 546 85 00 fax 31 45 546 85 99 20
- Adj products llc 6122 s eastern ave los angeles ca 90040 usa tel 323 582 2650 fax 323 725 6100 web www adj com e mail info americandj com 20
- Auto sensing voltage 20
- Model inno pocket spot lzr 20
- Please note 20
- Specifications and improvements in the design of this unit and this manual are subject to change without any prior written notice 20
- This fixture contains a automatic volt age switch which will auto sense the voltage when it is plugged into the power source 20
