Inno Pocket Spot LZR 13 Channel Mode
Channel Value Function
1 0 - 255 PAN MOVEMENT 0° - 540°
2 0 - 255 TILT MOVEMENT 0° - 210°
3 COLORS
0 - 7 WHITE
8 - 14 RED
15 - 21 ORANGE
22 - 28 YELLOW
29 - 35 GREEN
36 - 42 UV
43 - 49 LIGHT BLUE
50 - 56 PINK
57 - 127 SPLIT COLORS
128 - 189 COLOR SCROLL FAST - SLOW
190 - 193 STOP
194 - 255 COLOR SCROLL SLOW - FAST
4 GOBO WHEEL
0 - 7 OPEN
8 - 15 GOBO 1
16 - 23 GOBO 2
24 - 31 GOBO 3
32 - 39 GOBO 4
40 - 47 GOBO 5
48 - 55 GOBO 6
56 - 63 GOBO 7
64 - 71 OPEN SHAKE
72 - 79 GOBO 1 SHAKE
80 - 87 GOBO 2 SHAKE
88 - 95 GOBO 3 SHAKE
96 - 103 GOBO 4 SHAKE
104 - 111 GOBO 5 SHAKE
112 - 119 GOBO 6 SHAKE
120 - 127 GOBO 7 SHAKE
128 - 189 GOBO SCROLL FAST - SLOW
190 - 193 STOP
194 - 255 GOBO SCROLL SLOW - FAST
Inno Pocket Spot LZR 13 Channel Mode
Channel Value Function
5 SHUTTER/STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 RANDOM STROBE
248 - 255 OPEN
6 0 - 255 MASTER DIMMER 0% - 100%
7 LASER
0 - 9 NO ROTATION
10 - 119 CLOCKWISE ROTATION FAST - SLOW
120 - 134 NO ROTATION
135 - 247 COUNTER- CLOCKWISE ROTATION
SLOW - FAST
248 - 255 NO ROTATION
8 LASER SHUTTER/STROBE
0 - 7 OFF
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 255 OPEN
9 0 - 255 LASER MASTER DIMMER 0% - 100%
10 PAN/TILT MACRO
0 - 16 NO FUNCTION
17 - 35 MACRO 1
36 - 55 MACRO 2
56 - 75 MACRO 3
76 - 95 MACRO 4
96 - 115 MACRO 5
116 - 135 MACRO 6
136 - 155 MACRO 7
156 - 175 MACRO 8
176 - 195 MACRO 9
