Please Note: Specications and improvements in the design
of this unit and this manual are subject to change without any
prior written notice.
Inno Pocket Spot LZR Specifications
Model: Inno Pocket Spot LZR
Voltage: 100 - 240V, 50/60Hz
LED: 1 x 12W White LED
Laser: 30mW Green Diodes
Power Consumption: 48W
Dimensions: 5.75”(L) x 6.25”(W) x 10.75”(H)
147 x 159 x 271mm
Weight: 7 Lbs. / 3.4 kgs.
Beam Angle: 13 Degrees
Fuse: 2 Amp
Duty Cycle: None
DMX: 3 DMX Channel Modes: 13/14/16
Colors: 7 + White
Gobos: 7 + Spot
Sound Active: Yes
Working Position: Any Safe, Secure Position
Warranty: 2 Year (730 days) (LEDs)
1 Year (365 days) (Laser)
ADJ Products, LLC
6122 S. Eastern Ave. Los Angeles, CA 90040 USA
Tel: 323-582-2650 / Fax: 323-725-6100
Web: www.adj.com / E-mail: info@americandj.com
A.D.J. Supply Europe B.V.
Junostraat 2
6468 EW Kerkrade
Netherlands
service@adjgroup.eu / www.adj.eu
Tel: +31 45 546 85 00 / Fax: +31 45 546 85 99
Auto Sensing Voltage: This xture contains a automatic volt-
age switch, which will auto sense the voltage when it is plugged
into the power source.
