ADJ Products, LLC - www.adj.com - Inno Pocket Spot LZR Instruction Manual Page 28 ADJ Products, LLC - www.adj.com - Inno Pocket Spot LZR Instruction Manual Page 29
Inno Pocket Spot LZR 14 Channel Mode
Channel Value Function
5 SHUTTER/STROBE
0 - 7 BLACKOUT
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 139 OPEN
140 - 181 SLOW OPEN - FAST CLOSE
182 - 189 OPEN
190 - 231 FAST OPEN - SLOW CLOSE
232 - 239 OPEN
240 - 247 RANDOM STROBE
248 - 255 OPEN
6 0 - 255 MASTER DIMMER 0% - 100%
7 LASER
0 - 9 NO ROTATION
10 - 119 CLOCKWISE ROTATION FAST - SLOW
120 - 134 NO ROTATION
135 - 247 COUNTER- CLOCKWISE ROTATION
SLOW - FAST
248 - 255 NO ROTATION
8 LASER SHUTTER/STROBE
0 - 7 OFF
8 - 15 OPEN
16 - 131 STROBING SLOW - FAST
132 - 255 OPEN
9 0 - 255 LASER MASTER DIMMER 0% - 100%
10 PAN/TILT MACRO
0 - 16 NO FUNCTION
17 - 35 MACRO 1
36 - 55 MACRO 2
56 - 75 MACRO 3
76 - 95 MACRO 4
96 - 115 MACRO 5
116 - 135 MACRO 6
136 - 155 MACRO 7
156 - 175 MACRO 8
176 - 195 MACRO 9
Inno Pocket Spot LZR 14 Channel Mode
Channel Value Function
10 PAN/TILT MACROS
196 - 215 MACRO 10
216 - 235 MACRO 11
236 - 255 MACRO 12
11 PAN/TILT MACRO SPEED
0 - 255 SLOW - FAST
12 PAN/TILT SPEED
0 - 255 FAST - SLOW
13 BLACKOUT/RESET FUNCTIONS
0 - 69 NOTHING
70 - 79 BLACKOUT WITH PAN/TILT MOVE
80 - 89 NOTHING
90 - 99 BLACKOUT WITH COLOR CHANGE
100 - 109 NOTHING
110 - 119 BLACKOUT WITH GOBO CHANGE
120 - 199 NOTHING
200 - 209 RESET ALL
210 - 249 NOTHING
250 - 255 SOUND ACTIVE MODE
14 DIMMER MODE
0 - 20 STANDARD
21 - 40 STAGE
41 - 60 TV
61 - 80 ARCHITECTURAL
81 - 100 THEATRE
101 - 255 DEFAULT DIMMER SETTING
