Short information
RE3 UHF
Wireless
2018
-12 | 01 | F.01U.362.808 Installation manual Electro-
Voice
RE3-BPCL-5L
Bodypack set, cardioid mic 488-524MHz
RE3-BPCL-5H
Bodypack set, cardioid mic 560-596MHz
RE3-BPCL-6M
Bodypack set, cardioid mic 653-663MHz
RE3-BPCL-8M
Bodypack set, cardioid mic 823-865MHz
RE3-BPCL-T
Bodypack set, cardioid mic 803-806MHz
RE3-BPHW-5L
Bodypack set, headworn mic 488-524MHz
RE3-BPHW-5H
Bodypack set, headworn mic 560-596MHz
RE3-BPHW-6M
Bodypack set, headworn mic 653-663MHz
RE3-BPHW-8M
Bodypack set, headworn mic 823-865MHz
RE3-BPHW-T
Bodypack set, headworn mic 803-806MHz
RE3-BPGC-5L
Bodypack instrument set 488-524MHz
RE3-BPGC-5H
Bodypack instrument set 560-596MHz
RE3-BPGC-6M
Bodypack instrument set 653-663MHz
RE3-BPGC-8M
Bodypack instrument set 823-865MHz
RE3-BPGC-T
Bodypack instrument set 803-806MHz
RE3-BPNID-5L
Bodypack set, no input device 488-524MHz
RE3-BPNID-5H
Bodypack set, no input device 560-596MHz
RE3-BPNID-6M
Bodypack set, no input device 653-663MHz
RE3-BPNID-8M
Bodypack set, no input device 823-865MHz
RE3-BPNID-T
Bodypack set, no input device 803-806MHz
2.1 Shipping contents
This manual is packaged in a preconfigured set containing a receiver and its supplied accessories,
as well as a transmitter and its supplied accessories. The delivered set configurations vary.
2.1.1 Items contained in all sets
Quantity
Component
1
Receiver
2
Receiver antennas
1
Receiver power supply with four power convention specific AC plug clips
2
Rack-mount brackets
2
Rack-mount bracket hole filler plugs
1
Pack of four (4) screws to mount rack brackets
1
Safety booklet
1
Installation manual
