Keylock icon

Indicates transmitter is in lock mode.

8.3 Installing batteries

 While gripping the transmitter handle/battery cover section (item 2 shown above) with one

hand, grip the control section (item 3 shown above) with the other hand. Using a left-hand

twist, unscrew the control section until it is free from the handle. Slide the control section

away from the handle until the battery compartment (item 6 shown above) is fully exposed.

 Gently rotate the hinged protective battery cover to expose the battery chamber. Note the

battery polarity markings (+ and -) on the protective cover. Both positive (+) contacts are

adjacent to the control section male threads.

 Install two fresh, high quality AA alkaline batteries (or fully charged AA size NiMH

rechargeable cells) paying close attention to match the polarity markings (+ and -) on each

battery to the polarity markings (+ and -) of the battery contacts as shown on the battery

cover.

 Once both new batteries are properly installed, rotate the hinged protective battery cover

downward until the cover is in contact with the batteries.

 Applying the same gripping technique used while opening the transmitter to expose the

batteries, gently slide the battery compartment back inside the handle until the control

section can move no further. Using a right hand twist, screw the control section onto the

handle section until it is tightly threaded on. Be careful not to overtighten the threads.

8.4 RE3-HHT setup menu

Editing any of the following parameters locally on the transmitter is possible. These edits will

override the settings synchronized from the mated receiver. Additionally, any parameter value

changes made locally on the transmitter may be overwritten the next time the transmitter is synced

to the mated receiver if those parameters are selected in the receiver’s sync configuration.

NOTE: No local edits will be possible if the transmitter is in Keylock mode (lock icon displayed).

See unlocking instructions below.

NOTE: Press and hold SET for three seconds to enter parameter edit mode. The frequency in

millions will begin flashing. Once in parameter edit mode, pressing SET multiple times will advance

through the adjustable parameters one parameter per press. The press and hold of SET to enter

parameter edit mode counts as the first SET button press.
