Accessories for RE3
RE3 UHF
Wireless
2018
-12 | 01 | F.01U.362.808 Installation manual Electro-
Voice
10 Accessories for RE3
Additional transmitters
RE3-HHT76
RE3 Handheld transmitter with ND76 head
RE3-HHT86
RE3 Handheld transmitter with ND86 head
RE3-HHT96
RE3 Handheld transmitter with ND96 head
RE3-HHT420
RE3 Handheld transmitter with RE420 head
RE3-HHT520
RE3 Handheld transmitter with RE520 head
RE3-BPT
RE3 Bodypack transmitter
Extra receiver
RE3-RX
RE3 1/2-space receiver with power supply
Antenna distribution
RE3-ACC-AASP
Active antenna splitter, 2-in, 8-out
RE3-ACC-PASP
Passive splitter kit
Extension antennas and boosters
RE3-ACC-PLPA
Passive log periodic antenna
RE3-ACC-ALPA
Active log periodic antenna
RE3-ACC-RFAMP
Active RF antenna booster
Rack mounting
RE3-ACC-RMK1
Rack mount kit for single RE3 receiver
RE3-ACC-RMK2
Rack mount kit for two RE3 receivers
Handheld transmitter microphone heads
ND76-RC3
Wireless head with ND76 capsule
ND86-RC3
Wireless head with ND86 capsule
ND96-RC3
Wireless head with ND96 capsule
RE420-RC3
Wireless head with RE420 capsule
RE520-RC3
Wireless head with RE520 capsule
Handheld transmitter accessory
RE3-ACC-HHTSA1
Stand adapter for RE3-HHT transmitter
RE3 series bodypack transmitter input devices
RE3-ACC-OL3
Omnidirectional lavalier mic with 4-pin mini plug
RE3-ACC-CL3
Cardioid lavalier mic with 4-pin mini plug
RE3-ACC-HW3
Headworn mic with 4-pin mini plug
RE3-ACC-GC3
Instrument cable; 1/4" to 4-pin mini plug
