ELECTRO VOICE RE3-BPHW-8M [66/72] Re520 rc3 condenser supercardioid microphone head
![ELECTRO VOICE RE3-BPHW-8M [66/72] Re520 rc3 condenser supercardioid microphone head](/views2/2008230/page66/bg42.png)
66
en |
Technical data
RE3 UHF
Wireless
2018
-12 | 01 | F.01U.362.808 Installation manual Electro-
Voice
RE520-RC3 condenser supercardioid microphone head
Element Type:
Self-biased Condenser
Frequency Response:
40 Hz to 20,000 Hz
Polar Pattern:
Supercardioid
Sensitivity: Open Circuit Voltage. 1
kHz:
5.6mV/Pascal
(
-45 dBV/PA)
Clipping (max SPL):
139 dB SPL (1% THD)
Self Noise:
22 dB SPL "A" weighted (0 dB = 20 micropascals)
Dynamic Range:
117 dB
Signal-to-Noise Ratio:
72 dB
Power Requirements:
4-8 VDC
Polarity:
Positive pressure on diaphragm produces positive voltage at
center contact relative to ground contact
Electrical Contact:
3-Ring / 3-Pin
Threaded Coupling:
1.25” Diameter
28 UN
-2A Thread Pitch
Finish:
Black polyurethane paint
Materials:
Aluminum, steel, steel wire grille screen
Dimensions, Length:
Diameter:
3.36 in (85.3 mm)
1.95 in (49.6 mm)
