LINE 6 POD X3 [12/100] Show the delay settings
![LINE 6 POD X3 [12/100] Show the delay settings](/views2/2009069/page12/bgc.png)
Tutorials
1•4
8. Show the Delay settings.
Double Press
9. Set the Delay tempo, and set it to run post (after the Amp Model).
Press down
to select
lower row.
Ta p is set to
quarter note.
Set CONFIG
to POST.
Tap delay temo.
