LINE 6 POD X3 [87/100] Feed one guitar amp
![LINE 6 POD X3 [87/100] Feed one guitar amp](/views2/2009069/page87/bg57.png)
Example Setups
7•3
3. Set the rst OUTPUTS page (1/4-inch jacks Outputs):
Mode: Studio/Direct Tone 1•
Feed One Guitar Amp
1. Connect 1/4-inch output(s) to your amp or speaker system.
2. Set the rst OUTPUTS page (1/4-inch Outputs):
Mode: Combo Front, Combo Pwramp, Stack Front, or Stack PwrAmp.•
Lows, Focus, Highs: as desired•
Tone 1: On•
Tone 1 Pan: Center•
Tone 2: On•
Tone 2 Pan: Center•
3. Check your Master Volume.
Select the loudest preset/settings you intend to use. •
Play your instrument and turn Master Volume as high as you can without clipping •
the amp/speakers you’re feeding.
Feed Two Guitar Amps, One for Tone 1 and One for Tone 2
1. Connect the left 1/4-inch output to one amp, and the right 1/4-inch output to the
other.
2. Set the rst OUTPUTS page (1/4-inch Outputs):
Mode: Combo Front, Combo Pwramp, Stack Front, or Stck PwrAmp.•
Lows, Focus, Highs: as desired•
Tone 1: On•
