LINE 6 POD X3 [13/100] Select the eq

Tutorials

1•5

10. Select the EQ.

Press to show

the Home Page.

Press to turn

EQ on/off.

Double-press

to show EQ

settings.

Press up/down/left/

right to select EQ.

11. Tweak the EQ.

There is no model

select for EQ.

Press up/down to

select upper/lower

row.
