LINE 6 POD X3 [90/100] Electric guitar to on stage amp and direct out vocals acoustic etc to direct out only
![LINE 6 POD X3 Live [90/100] Electric guitar to on stage amp and direct out vocals acoustic etc to direct out only](/views2/2009069/page90/bg5a.png)
Example Setups
7•6
Select the loudest preset/settings you intend to use. •
Play your instrument and turn Master Volume as high as you can without clipping •
the amp/speakers you’re feeding.
Electric Guitar to On-Stage Amp and Direct Out + Vocals/
Acoustic/etc. to Direct Out Only
1. Connect your electric guitar to Guitar In.
2. Connect your microphone to the Mic In, or your acoustic, etc. to the Aux or Line In.
3. On the INPUTS page:
Tone 1: Guitar•
Tone 2: select the (inputs) you’re using for your Mic, acoustic, etc.•
4. Connect 1/4-inch output(s) to your amp or speaker system.
5. Connect XLR output(s) to your recorder, mixer or PA.
6. On rst OUTPUTS page (1/4-inch outputs):
Mode: Combo Front, Combo Pwramp, Stack Front, or Stck PwrAmp.•
Lows, Focus, Highs: as desired•
Tone 1: On•
Tone 1 Pan: center•
Tone 2: Mute (so your vocal/acoustic/etc. doesn’t go to your on-stage amp)•
7. On second OUTPUTS page (Studio/Direct Mix):
Mode: Studio/Direct•
Tone 1: On•
Tone 1 Pan: Left•
Tone 2: On•
Tone 2 Pan: Right•
