Reference: Configuration & Setup
6•1
re f e r e n C e : Co n f i G u r a T i o n & se T u P
Inputs
Press the Inputs button to get to the Inputs page:
INPUTS
TONE 1TONE 2
GUITAR SAME
DIGITAL VARIAX
S/PDIF
DISABLE
GLOBAL
CONTROL
Here, you can route your hardware inputs to Tone 1 and Tone 2.
Tone1 – pick an input to get routed to Tone 1.
For POD X3, you can choose Guitar or Microphone.
•
For POD X3 Live, you can also choose Aux, Variax, Guitar + Aux, Guitar + Variax, •
or Guitar + Variax + Aux.
For POD X3 Pro, your choices are Gtr 1, Mic 1, Line 1, Variax, Gtr 1+Gtr 2, Gtr
•
1+Variax, Gtr 1+Gtr 2+Variax, Gtr 2, Line 2, Mic 2, Guitar Stereo, Mic Stereo,
Line Stereo, Digital Left, Digital Right and Digital Stereo.
Tone 2 – pick an input to get routed to Tone 2.
For POD X3, you can choose Same as Tone 1, Guitar, or Microphone.
•
For POD X3 Live, you can also choose Aux, Variax, Guitar + Aux, Guitar + Variax, •
or Guitar + Variax + Aux.
For POD X3 Pro, your choices include all of the Tone 1 input assignment choices
•
listed above, plus Same as Tone 1. Your Tone 2 input choices are restricted, however,
depending on the input you’ve selected for Tone 1. For example, when a Stereo
setting is selected for Tone 1 input, Tone 2 will automatically be set to Locked For
Stereo. In this mode, no other input selection will be available for Tone 2.
