LINE 6 POD X3 [88/100] Feed two guitar amps one wet and one dry
![LINE 6 POD X3 [88/100] Feed two guitar amps one wet and one dry](/views2/2009069/page88/bg58.png)
Example Setups
7•4
Tone 1 Pan: Full Left•
Tone 2: On•
Tone 2 Pan: Full Right•
3. Check your Master Volume.
Select the loudest preset/settings you intend to use. •
Play your instrument and turn Master Volume as high as you can without clipping •
the amp/speakers you’re feeding.
Feed Two Guitar Amps, One “Wet” and One “Dry”
1. Connect the left 1/4-inch output to one amp, and the right 1/4-inch output to the
other.
2. Set the rst OUTPUTS page, (1/4-inch Outputs):
Mode: Combo Front, Combo Pwramp, Stack Front, or Stck PwrAmp.•
Lows, Focus, Highs: as desired•
Tone 1: On•
Tone 1 Pan: Full Left•
Tone 2: On•
Tone 2 Pan: Full Right•
3. Check your Master Volume.
Select the loudest preset/settings you intend to use for your “dry” sound. •
Play your instrument and turn Master Volume as high as you can without clipping •
the amp/speakers that you’re using as your dry amp.
4. Set up your “dry” tone.
Dial in your dry sound on Tone 1, with little or no “wet” effects,•
Save your preset.•
5. Set up your “wet” tone.
