22
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
Overall Control
■DSP Type
The [DSP TYPE] button selects one of eight digital effects that you can use for extra depth and expressive
power. This button determines the type of effect to be used, while the [DSP DEPTH] button in the VOICE sec-
tion allow the depth of the effect to be individually set for each orchestration part.
ZPress the [DSP TYPE] Button ...............................................................................................................
Press the OVERALL CONTROL section [DSP TYPE] button. The
number of the current DSP type will appear on the LCD display panel.
XSelect a DSP Type ..................................................................................................................................
Use the [+] and [–] buttons, the number buttons, the data dial, or the
[DSP TYPE] button itself to select the desired DSP type (0 for OFF, or 1 …
8 as listed below). The default DSP type (1) can be recalled instantly by
pressing both the [+] and [–] buttons at the same time.
The DSP Types
1 Hall 1
2 Hall 2
3 Room 1
4 Room 2
5 Plate 1
6 Plate 2
7 Delay 1
8 Delay 2
NOTES
• DSP effects may sound different with different voices.
• The DSP Type setting is retained in memory even when the power
switch is turned off, as long as the backup batteries are installed or
the AC plug is connected.
These are simulations of the large plate reverb devices traditionally
used in professional recording studios.
Delay 1 produces a distinct series of delay repeats, while Delay 2 pro-
duces a smoother multiple-delay sound.
For a spacious reverb sound use one of the Hall settings. These effects
simulate the natural reverberation of a concert hall. Hall 2 has a longer
reverb time and therefore simulates a larger hall than Hall 1.
These settings add relatively short reverb effects to the sound that are
similar to the type of acoustic reverberation you might hear in different
rooms.
0 OFF
.....................................
1 HALL 1
2 HALL 2
3 ROOM 1
4 ROOM 2
DSP
TYPE
DSP TYPE
5 PLATE 1
6 PLATE 2
7 DELAY 1
8 DELAY 2
PSR-2700PSR-1700
021
–+
RESET
DspTyp=1–:Hall1 08:Showtune 001:GrandPno
AccOff DspTyp=1–:Hall1
