74
| | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | | |
MIDI Reception Modes
The [RECEIVE CH/CL/COM] button is used to specify the reception mode for each of the 16 MIDI channels,
the internal or external clock mode, and MIDI start/stop command reception mode.
■ Channel Reception Modes
The PSR-1700 and PSR-2700 allow any of five reception modes to be individually assigned to MIDI chan-
nels 1 through 16. The five modes are:
Mode “0” RX OFF: Reception disabled.
Mode “1” MULTI: Received MIDI note data directly controls the PSR-1700/PSR-2700 tone
generator. Different voices can be played on different channels.
Mode “2” REMOTE: Received MIDI note data is handled in the same way as data from the
PSR-1700/PSR-2700’s own keyboard.
Mode “3” CHORD: Received MIDI note data is interpreted as Auto Accompaniment chord
commands.
Mode “4” ROOT: Received MIDI note data is interpreted as Auto Accompaniment bass note
commands .
MIDI
NOTES
• If the PSR-1700/2700 receives more than one note at the same time while mode “4” (Root) is
selected, the last note will be interpreted as the Auto Accompaniment bass note.
NOTES
• “Clock Rx” and “Cmnd Rx” will appear on the display if you increment
above channel number 16 or below channel number 1. These selec-
tions are used for the Clock Mode and Start/Stop Mode functions
described below.
• Be sure to set the transmit channel to the same channel specified in
mode 2, 3, or 4.
ZPress the [RECEIVE CH/CL/COM] Button & Select a Channel...........................................................
Press the [RECEIVE CH/CL/COM] button, then use the [+] and [–]
buttons, the number buttons, the data dial, or the [RECEIVE CH/CL/
COM] button itself to select the MIDI channel (1 … 16) for which you
want to specify a new reception mode. The channel number appears on the
right of the LCD display panel.
PSR-2700PSR-1700
RxCh0–1=1:Multi
08:Showtune 001:GrandPno
AccOff RxCh0–1=1:Multi
RECEIVE
CH/CL/COM
MODE
................
0 RX OFF
1 MULTI
2 REMOTE
3 CHORD
4 ROOT
XSelect the Desired Mode ........................................................................................................................
Use the [+/–] button in the number-button row to select the desired re-
ception mode for the selected channel. The modes are selected in sequence
each time the [+/–] button is pressed, and the mode number appears on the
LCD display panel.
NOTES
• The currently selected reception mode is retained in memory even
when the power switch is turned off, as long as backup batteries are
installed or an AC plug is connected.
+
–
1
_ _
9
