Operation

Intimidator Spot 110 User Manual Rev. 2

Master/Slave Mode

The Master/Slave mode allows a single Intimidator Spot 110 product (the “master”) to control the actions of

one or more Intimidator Spot 110 products (the “slaves”) without the need of a DMX controller. The master

product will be set to operate in either standalone mode or with the IRC-6, while the slave products will be

set to operate in slave mode. Once set and connected, the slave products will operate in unison with the

master product.

Configure the products as indicated below.

Slave products:

1. Press <MENU> repeatedly until ChMd shows on the display.

2. Use <UP> or <DOWN> to select 6Ch.

3. Press <ENTER>.

4. Press <MENU> repeatedly until Addr shows on the display.

5. Use <UP> or <DOWN> to select A001

6. Press <ENTER>.

7. Connect the DMX input of the first slave product to the DMX output of the master product.

8. Connect the DMX input of the subsequent slave products to the DMX output of the previous slave

product.

9. Finish setting and connecting all the slave products.

Master product:

1. Set the master product to operate in standalone mode.

2. Make the master product the first product in the DMX daisy chain.

• Configure all the slave products before connecting the master to the daisy chain.

• Never connect a DMX controller to a DMX string configured for Master/Slave operation

because the controller may interfere with the signals from the master.

• Do not connect more than 31 slaves to the master.
