Page 6 of 16
Operation
Intimidator Spot 110 User Manual Rev. 2
4. Operation
Control Panel Operation
To access the control panel functions, use the four buttons located underneath the display. Please refer to
the Product Overview
to see the button locations on the control panel.
Menu Map
Configuration (DMX)
The Intimidator Spot 110 works with a DMX controller. Information about DMX is in the CHAUVET DMX
Primer, which is available from the Chauvet website http://www.chauvetlighting.com/downloads/
DMX_Primer_rev05_WO.pdf.
Starting Address
When selecting a starting DMX address, always consider the number of DMX channels the selected DMX
mode uses. If the starting address is set too high, access to some of the product’s channels could be
restricted.
The Intimidator Spot 110 uses up to 15 DMX channels, which defines the highest configurable address to
501.
For information about the DMX protocol, download the DMX Primer from www.chauvetdj.com
.
To select the starting address, do the following:
1. Press <MENU> repeatedly until Addr shows on the display.
2. Press <ENTER>.
3. Use <UP> or <DOWN> to select the starting address, from A001–512.
4. Press <ENTER>.
Button Function
<MENU> Press to find an operation mode or to back out of the current menu option
<UP> Press to scroll up the list of options or to find a higher value
<DOWN> Press to scroll down the list of options or to find a lower value
<ENTER> Press to activate a menu option or a selected value
Mode Programming Levels Description
Address Addr A001–512 Sets the DMX starting address
Channel
Mode
ChMd
6Ch
Selects the DMX personality
12Ch
Show Mode ShMd
Auto SP 1–10 Selects Auto mode and speed
Soud Selects sound-active mode
Sensitivity SEnS 0–100 Sets the sound sensitivity
Pan Reverse PAn
no Normal pan operation
YES Reverse pan operation
Tilt Reverse tILt
no Normal tilt operation
YES Reverse tilt operation
Manual
Mode
MAnu
PAn P 0–255 Manual pan control
tILt t 0–255 Manual tilt control
CoLo C 0–255 Manual color control
Gobo G 0–255 Manual gobo control
dIMM d 0–255 Manual dimmer control
Stro S 0–255 Manual strobe control
Version uEr u_ _ _ Displays current firmware version
Factory
Reset
LoAd
no
Loads factory defaults
YES
