Technical Specifications

Intimidator Spot 110 User Manual Rev. 2

6. Technical Specifications

Dimensions and Weight

Note: Dimensions in inches rounded to the nearest decimal digit.

Power

Light Source

Photometrics

Thermal

DMX

Ordering

Length Width Height Weight

7.5 in (190 mm) 5 in (127 mm) 11 in (279 mm) 5 lb (2.3 kg)

Power Supply Type Range Voltage Selection

Switching (internal) 100 to 240 VAC, 50/60 Hz Auto-ranging

Parameter 120 V, 60 Hz 230 V, 50 Hz

Consumption 41 W 38 W

Operating current 0.6 A 0.4 A

Fuse F 1 A, 250 V F 1 A, 250 V

Power I/O U.S./Worldwide UK/Europe

Power input connector IEC IEC

Power cord plug Edison (U.S.) Local plug

Type Color Quantity Power Current Lifespan

LED Cool white 1 10 W 2.1 A 50,000 hours

Strobe Rate Beam Angle Illuminance @ 2 m

0 to 23 Hz 13° 1,561 lux

Maximum External Temperature Cooling System

104 °F (40 °C) Fan-assisted convection

I/O Connector Channel Range

3-pin XLR 6 or 12

Product Name Item Code UPC Number

Intimidator Spot 110 07011494 781462218423
