TECHNICAL PASSPORT ENGLISH

Oven

Telescopic runners with folding

clip

WARNING

The runners must be placed at

height 2, starting from below. Figure 12.

1. Remove the protective lm.

2. Hook the large clips on the upper

rail and extend the runner until it hooks

on the small clips on the lower rail.

Figure 12.

3. You will hear a «click» when the

runner is correctly secured. Figure 13.

4. The notch to x the tray/support

must remain at the front part of the

oven. Figure 13.

Telescopic runners with direct

clip

WARNING

The single extraction runners must

be placed at heights 1, 2, 3 and 5

starting from below. Figure 14.

The double extraction runners must

be placed at heights 1, 2 and 3 starting

from below. Figure 15.

In 45 cm ovens, the telescopic

runners are positioned at height 1.

Figure 16.

1. Hook the clip on the top rail at the

desired level. Figure 17.

2. You will hear a «click» when the

runner is correctly secured. Figure 18.

3. The notch to x the tray/rack

support must emain at the front part of

the oven. Figure 18.
