Gaggenau CG 492 [15/48] Important notes
![Gaggenau CG 492 [15/48] Important notes](/views2/1113321/page15/bgf.png)
Please observe the general safety notes and the
important information.
The installing technician is responsible for perfect
functioning of the appliance at its installa tion
location.
He must show the user how to switch off the
electricity and gas supply whenever required.
After unpacking, check the appliance for any
transportation damage and report this immediately
to the transportation company.
Caution:
before connecting the appliance, please check
whether the local connection conditions such as
gas type, gas pressure and mains voltage match the
appliance settings. This gas hob conforms to the
categories that are specified on the rating plate.
The rating plate can be found on the appliance and
additionally on the quality control slip which is
included with these instructions. By replacing
nozzles, it is possible to set the appliance to any
gas listed on the rating plate.
If the data should not match, the appliance must
be changed over to the required gas type and the
available pressure.
As this gas hob is not intended for connection to an
exhaust gas system, pay attention to the applicable
installation conditions.
The appliance may be installed in kitchen
combinations made of wood or similar combustible
materials without taking additional measures. The
rear wall must consist of non-combustible material.
A minimum distance of 300 mm from heat-sensitive
items of furnishing or contact surfaces (cupboard
side panel) must be observed.
The hob conforms to appliance class 3 and must be
installed in the worktop as shown in the installation
sketch.
Do not install the appliance under a suspended
cupboard. For installation under a vapour extractor,
a minimum clearance of 760 mm must be
observed. Wall trims must be heat-resistant, and the
minimum distance between the hob and the wall
trim is at least 35 mm.
The appliance must be installed and connected by
an authorised gas installer. The installation must
conform with all current regulations of the gas
supply companies and the regional construction
regulations.
Technical modifications reserved.
13
