ETR 750 - ETR 900J

ENGLISH

6. ASSEMBLY INSTRUCTIONS

MOUNTING THE GRIP

FIG. 2

 Press the grip on the tube until it goes into

place, keeping the inclined part of the grip facing

the motor.

 Slide the grip along the rod until it reaches a

comfortable height.

 Fit the screw (A) into the grip, fit the washer (B)

and tighten the wing nut (C).

MOUNTING THE GUARD

FIG. 3

 Attach the guard to the tube, with the guard fac-

ing the opposite side of the motor (A), and slide

it until it leaves the clamp and lies over the alu-

minium head (B).

 Rotate the guard by 180° and position it in its

seat on the aluminium head (C).

 Position the guard extension (D).

 Fit the Ø4.3x9 washers and insert the M4x14

screws.

 Tighten the screws with the supplied wrench (E).

WARNING: Perform the operation taking care not to

knock the cord cutter as this may cause injuries!

ATTENTION: Never work without the guard. The

guard must always be fitted with the cord cutter!

MOUNTING/DISMOUNTING THE CUTTING ASSEMBLY (FOR

DISMOUNTABLE MODELS)

FIG. 4

 Align the release button (A) with the hole in the

guide (B) to simplify installation.

 Hold the dismountable cutting assembly firmly

and push it into the clamp until the release but-

ton (A) enters the hole in the clamp (B).

 Tighten the knob (D) (right-hand thread). Make

sure it is perfectly tight before using the unit.

To dismount the cutting assembly, proceed in re-

verse order:

 Loosen the knob (D) (right-hand thread).

 Press down on the release button (A).

 Slide the cutting assembly off the clamp.

7. PREPARATION

CLOTHING

Never use the appliance barefooted or wearing

sandals. Never use the appliance when wearing

loose clothing that could get caught up in it. When

working, wear long trousers, safety boots or shoes

with non-slip soles, goggles and a shield protecting

your face from flying objects, gloves (preferably

leather) and anti-noise ear muffs or helmet. In work

areas where there is a risk of falling objects, pro-

tect your head with a safety helmet.

ELECTRICAL CIRCUIT

FIG. 5

Before connecting the appliance to the electricity

supply, check that the mains voltage and fre-

quency are compatible with the operating voltage

and frequency of the machine (see rating plate).

Connect the machine to a socket with differential

switch (circuit breaker) using an approved outdoor

cable. Always fix the extension cable (A) to the

cable holder located on the motor casing.

ATTENTION: To protect the electrical connection, do

not tug on the cable when using the appliance and

grip the plug and socket when disconnecting the ca-

ble.

8. USE

SCOPE

Use the edge trimmer fitted with just the cord head

to cut grass – especially around obstacles – and to

trim thin weeds and wild vegetation near ground

level. The cord head is particularly suitable for fin-

ishing operations such as trimming around posts

and trees.

ATTENTION: The standard version of the brush cutter

cannot be used in other ways.

ADJUSTING THE LENGTH OF THE NYLON CORD

Always check the length of the cord in the supplied

head before use. This head features a semi-auto-

matic system for adjusting cord length. When the

cord is short, start the machine and hit the cord

head on soft ground a few times. The cord comes

out automatically. Excessive cord length is cut by

the adjustment blade mounted on the guard.

RECOMMENDATIONS FOR USE

FIG. 6

 Observe the relevant safety instructions when

using the brushcutter.

 Carry the power tool on your r.h. side.

 Approach the area to be cleared with the motor

switched OFF; then start the motor before dip-

ping the cutter into the working area.

 With your thumb, initially press the locking but-

ton (1) and then additionally the ON/OFF switch

(2) with your index finger. Then release the lock-

ing button again. Release the ON/OFF switch to

switch the motor OFF again.

 Work at a regular pace and move from side to

side as though you were using a traditional

scythe. Do not incline the cord head while work-

ing. Try and cut a small area to the right height.

Keep the cord head at the same distance from

the ground in order to obtain a uniform cutting

height.

 Immediately switch OFF the motor, if you notice

any unusual vibrations or cuttings have wrapped

themselves around the cutting tool or have

jammed near the guard. Pull the mains plug

from its socket and clear the cutting tool of

grass, brush etc.

 Check the entire power tool for perfect condi-

tion.

 When using the nylon head, always ensure that

you operate only with the correct length of line.

When the guard is fitted, the line will always be

trimmed to the permissible length automatically

(a line trimming blade is fitted into the guard

bar).
