4.4 IGNITION KEY (3)
Must be fully inserted or the engine will not start. Do not turn
the key!
1. Key fully inserted – engine can start.
2. Key pulled out – engine cannot start.
4.5 STARTING HANDLE (1)
Manual cord start with rewinding.
4.6 DIPSTICK (8)
For filling and checking the oil level in the engine.
The dipstick has two level marks:
FULL = maximum oil level
ADD = minimum oil level
4.7 FILLER CAP (7)
For filling with petrol.
4.8 FUEL COCK (6)
The fuel cock opens the fuel supply to the carburettor. The
fuel cock shall always be closed when the machine is not in
use.
1. To the right - open.
2. Downwards - closed.
4.9 OIL DRAINING PLUG (14)
For draining the old engine oil when changing the oil.
4.10 START BUTTON – ELECTRICAL START (11)
Activates the electric starting motor.
4.11 ELECTRIC CABLE – ELECTRICAL START (12)
The cable supplies power to the starting motor. Connect the
cable to a 220/230 volt earthed socket via an earthed
extension lead. It is wise to use an earth fault breaker.
4.12 SPARK PLUG PROTECTION (22)
The protection is easily removable by hand. The spark plug
is located under the protection.
4.13 GEAR LEVER (17)
The machine has 6 forward gears and 2 reverse to regulate
the speed.
The gear lever must not be moved if the driving clutch
lever is depressed.
4.14 CLUTCH LEVER- DRIVING (20)
Engages the wheels when put into gear and the lever
is pushed towards the handle.
Situated on the left side of the handle.
4.15 CLUTCH LEVER- AUGER (16)
Connects the auger and fan when the lever is pushed
down towards the handle.
Situated on the right side of the handle.
4.16 ONE HAND CONTROL
The machine is equipped with one hand control, which
means that the clutch lever driving can lock the clutch lever
auger in activated position. Perform as follows:
1. Start the engine.
2. Press the clutch lever auger and the clutch lever driving.
3. Remove the hand from the clutch lever auger and it will
still be activated.
4.17 LEVER, CHUTE DEFLECTOR (18)
Lever at the panel for adjustment of the chute deflector (9)
1. Forwards – longer throwing distance.
2. Backwards – shorter throwing distance.
4.18 SHOES (13)
Used to set the height of the auger housing above the ground.
4.19 CHUTE DEFLECTOR (9)
The chute deflector is adjusted with the lever (18) and
determine the throwing distance.
4.20 HANDLE HEATING (21)
The machine is equipped with electrical handle heating. To
activate the heating, set the switch in the desired position:
Right - Full heating
Middle - No heating
Left - Light heating
The heating can be activated when the motor is running only.
4.21 HEADLAMP (15)
The headlamp is always activated when the motor is running.
4.22 CHUTE CLEARING TOOL (10)
The chute clearing tool is located in a holder on top of the
auger housing. The chute clearing tool must always be used
when cleaning the discharge chute and augur.
Always stop the engine before clearing the chute.
Never clear the snow discharge chute with your
hand. Risk of serious injury.
4.23 ADJUSTMENT SWITCH (19)
Changes the direction of the discharged snow.
Left - Chute turns to the left
Right - Chute turns to the right.
4.24 TRACTION CONTROL (24)
The traction control facilitates turning. When activated, the
left traction wheel is released, when the right wheel continue
driving.
Note: Activate the lever before beginning a turn. The lever is
more difficult to activate under heavy load.
4.25 DRIFT CUTTERS (23)
The drift cutters facilitate the throwing work when the snow
level is higher than the auger house. Fit the edge of the drift
cutters (15:T) through the hole in the auger house and secure
with the wing nut (15:U).
