54
ENGLISH
EN
Original instructions for use
7.6 ADJUSTING THE CONTROL WIRES
When the belts are adjusted or replaced, the control wires
must also be checked/adjusted (see below).
7.6.1 Adjusting auger wire
1. Remove the ignition key.
2. Dismantle the belt cover (1) by loosing the screw (2). See
fig. 16.
3. Actuate the auger drive lever and observe the tension
pulley. When the auger lever is in its half way of
movement against the handle, the pulley movement shall
stop against the belt (the pulley is allowed to move a few
mm during the last half of movement of the lever). See
fig. 13.
4. If necessary, unhook the spring and adjust the wire at the
screw, connected to the spring. See fig. 13.
5. Reassamble all parts in the reverse order.
7.6.2 Adjusting drive wire
See “7.5”.
7.7 REPLACING THE SHEAR BOLTS
(R IN FIG. 10)
The auger is fastened to the shaft by special bolts that are
designed to break if something gets stuck in the auger
housing.
Always use genuine spare parts. Other types of
bolts could cause serious damage to the machine.
1. Stop the engine.
2. Disconnect the ignition cable from the spark plug.
3. Ensure all the rotating parts have stopped.
4. Remove the object that has fastened in the auger.
5. Lubricate the auger shaft (see above).
6. Aligne the holes in the shaft and auger.
7. Remove the broken bolt parts.
8. Assemble a new original shear bolt.
7.8 HEADLAMP BULB
Only 27 W original spare part bulb is allowed to be
used. Bulbs with higher power will damage the
headlamp.
The headlamp bulb is fitted to the headlamp by a bayonet
socket. See fig. 14. To replace the bulb proceed as follows:
1. Turn the bulb about 30° CCW and pull it out.
2. Release the plastic locks at each side of the bulb and pull
off the cable connection from the bulb.
3. Fit the new bulb in the reverse order.
8 STORAGE
Never store the snow thrower with petrol in the
tank in a confined area with bad ventilation. Petrol
fumes could reach open flames, sparks, cigarettes
etc.
If the snow thrower is to be stored for a longer period than 30
days, the following measures are recommended:
1. Empty the petrol tank.
Empty the petrol tank outdoors when the engine is
cold. Do not smoke. Empty into a container
designed for petrol.
2. Start the engine and let it run until it stops due to lack of
fuel.
3. Change the engine oil if it has not been done for 3
months.
4. Remove the spark plug and empty a little engine oil
(about 30ml) in the hole. Crank the engine a couple of
times. Screw back the spark plug.
5. Clean the whole snow thrower thoroughly.
6. Lubricate all the parts as shown in LUBRICATING above.
7. Inspect the snow thrower for damage. Repair if necessary.
8. Touch up any paint damage.
9. Rust protect the metal surfaces.
10. Store the snow thrower indoors if possible.
9 IF SOMETHING BREAKS
Authorised service workshops carry out repairs and
guarantee service. Always use genuine spare parts.
Do you carry out simple repairs yourself? Always use
genuine spare parts. They fit perfectly and make the work
much easier.
Spare parts are available at your retailer and service station.
When ordering spare parts: Specify the model, year of
purchase, the engine model and type number.
10 PURCHASE TERMS
A full warranty is issued against manufacturing and material
defects. The user must carefully follow the instructions given
in the enclosed documentation.
Exceptions:
The warranty does not cover damage due to:
- Neglect by the user to acquaint themselves with
accompanying documentation
- Carelessness
- Incorrect and non-permitted use or assembly
- The use of non-genuine spare parts
- The use of accessories not supplied or approved by GGP
Neither does the guarantee cover:
- Wear parts such as drive belts, augers, headlights, wheels,
shear bolts and wires
- Normal wear
- Engines. These are covered by the engine manufacturer’s
warranties, with separate terms and conditions.
The purchaser is covered the national laws of each by each
country. The rights to which the purchaser is entitled with the
support of these laws are not restricted by this warranty.
