GENERAL INFORMATION 1-21
Torque and Locking Agent
Torque
Fastener
N·m kgf·m ft·lb
Remarks
Uni-Track:
Rocker Arm Nut 34 3.5 25
Ti e-rod Nuts 59 6.0 44
Steering
Steering Stem Head Nut (ZX1200-B1/B2) 54 5.5 40
Steering Stem Head Nut (ZX1200-B3) 78 8.0 57
Steering Stem Nut 20 2.0 15
Handlebar Bolts 34 3.5 25 L
Handlebar Weight Bolts – – – L
Handlebar Switch Housing Screws 3.5 0.36 31 in·lb
Frame
Wind Shield Mounting Screws 0.40 0.040 3.5 in·lb
Rear Frame Bolts and Nuts 44 4.5 32
Front Footpeg Holder Bolts 25 2.5 18
Rear Footpeg Holder Bolts 34 3.5 25
Side Stand Bracket Bolts 49 5.0 36
Side Stand Mounting Bolt and Nut 44 4.5 32
Side Stand Switch Bolt 8.8 0.90 78 in·lb L
Electrical System
Spark Plugs 13 1.3 115 in·lb
Alternator R otor Bolt 110 11 81
Stator Coil Bolts 22 2.2 16 L
Alternator Lead Holding Plate Bolts 8.5 0.87 75 in·lb L
Engine Ground Lead Terminal Bolt 10 1.0 89 in·lb
Alternator Cover Bolts 15 1.5 11
Crankshaft Sensor Cover Bolts 15 1.5 11 L
Crankshaft Sensor Bolts 6.0 0.60 53 in·lb
Camshaft Position Sensor Bolt 12 1.2 106 in·lb
Timing Rotor Bolt 39 4.0 29
Starter Motor Mounting Bolts
12 1.2 106 in·lb
Handlebar Switch Housing Screws
3.5 0.36 31 in·lb
Radiator Fan Switch
18 1.8 13
Water Tem perature Sensor 25 2.5 18 SS
Oil Pressure Switch 15 1.5 11 SS
Oil Pressure Switch Terminal Bolt 1.5 0.15 13 in·lb
Gear Position Switch Screws 4.0 0.40 35 in·lb L
Speed Sensor Bolt 10 1.0 89 in·lb
Fuel Level Sensor Bolts 6.9 0.70 61 in·lb
Front Brake Switch Light Screw 12 1.2 106 in·lb
Tail/Brake Light Assy Mounting Nuts 6.0 0.60 53 in·lb
