English | 13
Bosch Power Tools 1 618 C00 51C | (7.5.12)
f Do not operate the measuring tool in explosive environ-
ments, such as in the presence of flammable liquids,
gases or dusts. Sparks can be created in the measuring
tool which may ignite the dust or fumes.
f Always set up the measuring tool in such a manner that
the laser beams run far above or below eye level. This
ensures that damage to the eyes will not occur.
f Mark the area in which the measuring tool is being used
with suitable laser warning labels. This prevents per-
sons not involved from accessing the danger area.
f Do not store the measuring tool at locations, to which
unauthorised persons have access. Persons not familiar
with the operation of the measuring tool can cause harm to
themselves and to others.
f When using a class 3R measuring tool, observe possi-
ble national regulations. Non-observance of these regu-
lations can lead to injury.
f Make sure that the area of laser radiation is monitored
or shielded. The limitation of laser radiation to controlled
areas prevents eye damage to persons not involved.
f Before any work on the measuring tool itself (e.g. as-
sembling, maintenance, etc.) as well as when trans-
porting and storing, remove the battery pack or the
batteries from the measuring tool. Danger of injury when
accidentally actuating the On/Off switch.
f Do not open the battery pack. Danger of short-circuiting.
Protect the battery pack against heat, e.g.,
against continuous intense sunlight, fire,
water, and moisture. Danger of explosion.
f When battery pack is not in use, keep it away from oth-
er metal objects like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
f Under abusive conditions, liquid may be ejected from
the battery pack; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, addi-
tionally seek medical help. Liquid ejected from the bat-
tery pack may cause irritations or burns.
f In case of damage and improper use of the battery
pack, vapours may be emitted. Provide for fresh air and
seek medical help in case of complaints. The vapours
can irritate the respiratory system.
f Recharge only with the charger specified by the manu-
facturer. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another bat-
tery pack.
f Use the battery pack only in conjunction with your
Bosch measuring tool. This measure alone protects the
battery pack against dangerous overload.
f Use only original Bosch battery packs with the voltage
listed on the nameplate of your measuring tool. When
using other battery packs, e.g. imitations, reconditioned
battery packs or other brands, there is danger of injury as
well as property damage through exploding battery packs.
Keep the measuring tool and the laser tar-
get plate 10 away from cardiac pacemak-
ers. The magnets of the measuring tool and
laser target plate generate a field that can im-
pair the function of cardiac pacemakers.
f Keep the measuring tool and the laser target plate 10
away from magnetic data medium and magnetically-
sensitive equipment. The effect of the magnets of the
measuring tool and laser target plate can lead to irreversi-
ble data loss.
Remote control (GSL 2 Set)
Read and observe all instructions. SAVE
THESE INSTRUCTIONS FOR FUTURE REFER-
ENCE.
f Have the remote control repaired only through a quali-
fied repair person and only using identical replacement
parts. This will ensure that the functionality of the remote
control is maintained.
f Do not operate the remote control in explosive atmos-
pheres, such as in the presence of flammable liquids,
gases or dusts. Sparks can be created in the remote con-
trol which may ignite the dust or fumes.
Product Description and
Specifications
While reading the operating instructions, unfold the graphics
page with the illustration of the surface laser and the remote
control, and leave it open.
Intended Use
Surface laser
The measuring tool is intended for checking the flatness of
floor surfaces.
The measuring tool is suitable for indoor use.
Remote control (GSL 2 Set)
The remote control is intended for controlling surface lasers
indoors.
Product Features
The numbering of the product features refers to the illustration
of the surface laser and remote control on the graphics page.
Surface laser
1 Exit opening for laser beam
2 Laser warning label
3 Handle
4 Reception lens for remote control (GSL 2 Set)
5 Battery status indicator
6 Latch of battery lid
7 Battery lid
8 On/Off switch
9 Thumbwheel for height adjustment
10 Laser target plate
11 Measuring tip of the laser target plate
OBJ_BUCH-1545-004.book Page 13 Monday, May 7, 2012 9:33 AM
