14 | English
1 618 C00 51C | (7.5.12) Bosch Power Tools
12 Serial number of the surface laser
23 Battery pack*
Remote control
13 Outlet opening for infra-red beam
14 Button for fast rotation in anticlockwise direction
15 Button for slow rotation in anticlockwise direction
16 Button for step-by-step rotation in anticlockwise
direction
17 Button for step-by-step rotation in clockwise direction
18 Button for slow rotation in clockwise direction
19 Button for fast rotation in clockwise direction
20 Battery lid of the remote control
21 Battery lid latch of the remote control
22 Serial number
Accessories/Spare parts
24 Laser viewing glasses*
25 Case
* The accessories illustrated or described are not included as
standard delivery.
Technical Data
Surface laser GSL 2 GSL 2 Set
Article number
3 601 K64 000 3 601 K64 001
3 601 K64 070
3 601 K64 0R0
Remote-controlled, motor-driven rotation base
– z
Working range
1)
– without laser target plate
– with laser target plate
10 m
20 m
10 m
20 m
Levelling Accuracy
±0.3 mm/m ±0.3 mm/m
Self-levelling range, typically
±4° ±4°
Levelling duration, typically
<5s <5s
Operating temperature
–10 °C...+50 °C –10 °C...+50 °C
Storage temperature
–20 °C...+70 °C –20 °C...+70 °C
Relative air humidity, max.
90 % 90 %
Laser class
3R 3R
Laser type
630–670nm, <5mW 630–670nm, <5mW
C
6
11
Batteries (alkali-manganese)
Battery pack (lithium-ion)
4x1.5VLR06 (AA)
10.8 V
4x1.5VLR06 (AA)
10.8 V
Battery life
– Batteries (alkali-manganese)
– Battery pack (lithium-ion)
15 h
15 h
15 h
15 h
Weight according to EPTA-Procedure 01/2003
1.4 kg 1.4 kg
Dimensions (length x width x height)
210 x 195 x 205 mm 210 x 195 x 205 mm
Degree of protection
IP 54 (dust and splash water
protected)
IP 54 (dust and splash water
protected)
1) The working range can be decreased by unfavourable environmental conditions (e.g. direct sun irradiation).
For clear identification of your surface laser, see the serial number 12 on the type plate.
Remote control RC 2
Article number
3 601 K69 C00
Working range
2)
20 m
Operating temperature
–10 °C...+50 °C
Storage temperature
–20 °C...+70 °C
Remote control RC 2
Batteries
3x1.5VLR03(AAA)
Weight according to
EPTA-Procedure 01/2003
50 g
2) The working range can be decreased by unfavourable environmental
conditions (e.g. direct sun irradiation).
For clear identification of your remote control, see the serial number 22
on the type plate.
OBJ_BUCH-1545-004.book Page 14 Monday, May 7, 2012 9:33 AM
