─ 10 ─
Assembly
STEP 1
1. Attach two Adjustable Foot Plate (#14) to the Weight Stack Frame(#1).
2. Attach three Shroud Retainer Plate (#45) and one Right Shroud Retainer
Plate (#47) to the Weight Stack Frame(#1), using:
twelve M5*16 Flat Philips Screws (#97)
Note: Wrench Tighten Screws.
Here is the assembly instruction for Long Shroud !
