Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Weight Stack Frame 1 34 Bearing Φ47*Φ25*12 6

2 Main Frame 1 35 Bushing 4

3 Bottom Cross Brace 1 36 Right Tie Rod End M16*Φ16 2

4 Rear Cross Brace 1 37 Left Tie Rod End M16*Φ16 2

5 Sway Bracket 1 38 Plug RT50*100 2

6 Assistant Bracket 1 39 Grip 2

7 Joint Bracket 1 40 Shroud 1

8 Sway Pulley Bracket 1 41 Cable End 1

9 Right Press Arm 1 42 Brass Washer Φ35*Φ25.4*2 3

10 left Press Arm 1 43 Button 19

11 Seat Pad Support 1 44 Rear Shroud 1

12 Adjustable Support Sleeve 1 45 Shroud Retainer Plate 3

13 Adjustable Support 1 46 Front Shroud 1

14 Adjustable Foot plate 4 47 Right Shroud Retainer Plate 1

15 Top Plate 1 48 Top Front Shroud 1

16 Gas Spring 1 49 Front Support 1

20 Selector Pin W/Coil 1 50 Arc Bracket 1

21 4.5" Pulley 6 51 Rear Support 1

22 Cable 1 52 Top Rear Shroud-A 1

23 Back Pad 1 53 Spacer Φ10*Φ14*20 1

24 Seat Pad 1 54 Big Washer Φ55*13 3

25 Spacer 2 55 Aluminium Cap 2

26 Rod 2 56 Aluminium Grip Cap 2

27 Guide Rod 2 57 Aluminium Grip Ring 2

28 Nut 2 58 Retainning Snap Ring 1

29 Pivot Axle A 1 59 Foot Sleeve 2

30 Pivot Axle B 1 60 Weight Rubber Bumper 2

31 Pivot Axle C 1 61 Plug Bumper 3

32 Bearing Φ35*Φ19.1*13.5 2 62 Wheel 2

33 Bearing Φ50.8*Φ25.4*15.9 2 63 Spring 1
