─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

64 Plastic Tube Guide 2 95 Socket Head Cap Screw M8*30 1

Plug □25*50

1 96 Flat Head Cap Screw M10*30 4

Plug □44.5

1 97 Flat Philips Screw M5*16 17

67 Pulley Cover 3 98 Flat Philips Screw M5*25 2

68 Flat Washer Φ13*Φ24*1.5 6 99 Socket Set Screw 10-32*3.2 4

69 Flat Washer Φ38*Φ11*2 3 100 Hex Key s=5 1

70 Flat Washer Φ11*Φ20*2 32 101 Hex Key s=6 1

71 Flat Washer Φ9*Φ16*1.6 3 102 Hex Key s=8 1

73 Hex Nut M16 (Right) 2 103 Hex Key s=12 1

74 Hex Nut M16 (Left) 2 104 Hex Key s=3/32" 1

75 Hex Nut M6 2 105 Wrench 1

76 Nylon lock Nut M12 3 106 Lube 1

77 Nylon lock Nut M10 13 107 Hex Key s=4 1

78 Nylon lock Nut M8 2 108 Rivet Nut M8 2

79 Hex Head Bolt M12*120 1 109 Rubber Plug Φ29*Φ19*10 2

80 Hex Head Bolt M12*100 1 110 Spring Washer Φ8 2

81 Hex Head Bolt M12*85 1 111 Plug 2

82 Self-Tapping Screw ST4.2*10 4 112 Button Φ8.1*7 10

83 Hex Head Bolt M10*135 2 113 Flat Washer Φ9*Φ22*1.6 2

84 Hex Head Bolt M10*100 2 114 Plastic Cover Φ21*5.7 4

85 Hex Head Bolt M10*50 5 115 Plastic Washer Φ13*3 4

86 Hex Head Bolt M10*30 6 116 Connect Button Φ18*12 4

87 Hex Head Bolt M10*25 1 117 Top Rear Shroud 1

88 Hex Head Bolt M10*20 4 118 Short Shroud Retainer Plate 2

89 Button Head Cap Screw M10*65 2 119 Plug Φ95.4*61 2

90 Button Head Cap Screw M10*25 3 120 Side Cover 2

91 Button Head Cap Screw M8*55 1 121 Plastic Block 12

92 Button Head Cap Screw M6*12 2 122 L Bracket 2

93 Socket Head Cap Screw M16*40 4 123 Hex Head Bolt M8*30 2

94 Socket Head Cap Screw M10*50 2
