─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Weight Stack Frame 1 30 Plug 2

2 Main Frame 1 31 Plug RT50*100 3

3 Right Lat Arm 1 32 Button 19

4 Left Lat Arm 1 33 Plastic Tube Guide 2

5 Right Bracket 1 34 Foot Sleeve 1

6 Left Bracket 1 35 Weight Rubber Bumper Φ63.5*Φ19*25.42

7 Assistant Bracket 1 36 Plug Bumper Φ38*19.5 2

8 Bottom Cross Brace 1 37 Pulley Cover 4

9 Rear Cross Brace 1 38 Stopper 2

10 Seat Pad Support 1 39 4.5" Pulley 5

11 Back Pad 1 40 3.5" Pulley 3

12 Seat Pad 1 41 Plug Bumper Φ25*8 2

13 Arm Pad 2 42 Plug Bumper Φ25*15.2 1

14 Mobile Bracket 2 43 Top Front Shroud 1

15 Oval Flat 1 44 Rear Shroud 1

16 Spacer 2 45 Plastic Block 12

17 Aluminium Cap Φ60*Φ10.5*10.9 2 46 Front Shroud 1

18 Aluminium Cap Φ60*Φ10.5*10 1 47 Shroud Retainer Plate 3

19 Grip Φ30*Φ22*390 2 48 Right Shroud Retainer Plate 1

20 Adjustable Support 1 49 Support 1

21 Adjustable Foot plate 4 50 Top Rear Shroud A 1

22 Rod Assembly 2 51 Rear Support 1

23 Cable 1 1 52 Side Cover 2

24 Cable 2 1 53 Plug 48*22.7*R48 2

25 Selector Pin W/Coil 1 54 Adjustable Support Sleeve 1

26 Top Plate 1 55 Arc Bracket 1

27 Guide Rod 2 56 Aluminium Grip Cap 2

28 L Bracket 2 57 Aluminium Grip Ring 2

29 Weight Stack Space 2 58 Big Washer Φ31*Φ25.5*1.5 4
