─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

59 Spring 1 88 Nylon Lock Nut M12 2

60 Gas Spring 1 89 Nylon Lock Nut M10 15

61 Nut 2 90 Nylon Lock Nut M8 2

62 Bearing Φ47*Φ25*12 8 91 Hex Nut M6 2

63 Bearing Φ50.8*Φ25.4*15.9 2 92 Socket Set Screw 10-32*3.2 4

64 Plastic Washer Φ13*3 4 93 Button Head Cap Screw M8*15 2

65 Plastic Cover Φ21*5.7 4 94 Rivet Nut M8 2

66 Hex Head Bolt M10*20 2 95 Hex Key s=3 1

67 Hex Head Bolt M10*135 2 96 Hex Key s=5 1

68 Hex Head Bolt M10*100 2 97 Hex Key s=6 1

69 Hex Head Bolt M10*75 2 98 Hex Key s=8 1

70 Hex Head Bolt M10*50 4 99 Hex Key s=10 1

71 Flat Philips Screw M5*25 2 100 Hex Key s=3/32" 1

72 Hex Head Bolt M10*30 12 101 Hex Key s=3/16" 1

73 Hex Head Bolt M10*25 4 102 Wrench Φ6*117 1

74 Button Head Cap Screw M8*55 1 103 Lube 1

75 Button Head Cap Screw M6*12 2 104 Weight Plate 5LBS 2

76 Socket Head Cap Screw M12*35 2 105 Weight Plate 10LBS 3

77 Socket Head Cap Screw M10*120 1 106 Weight Plate 15LBS 10

78 Socket Head Cap Screw M10*50 2 107 Hex Key s=4 1

79 Socket Head Cap Screw M8*30 1 108 Button Φ8.1*7 9

80 Socket Head Cap Screw M4*15 2 109 Rubber Plug Φ29*Φ19*10 2

81 Flat Head Cap Screw M10*30 5 110 Hex Head Bolt M8*30 2

82 Flat Philips Screw M5*16 17 111 Spring WasherΦ8 2

83 Self-Tapping Screw ST4.2*10 4 112 Top Rear Shroud 1

84 Flat Washer Φ11*Φ20*2 42 113 Short Shroud Retainer Plate 2

85 Flat Washer Φ9*Φ16*1.6 3 114 Shroud 1

86 Flat Washer Φ11*Φ30*2 2 115 Flat Washer Φ9*Φ22*1.6 2

87 Connect Button 4
