─ 6 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

58 L Bracket 2 84 Socket Set Screw10-32*3.2 4

59 Aluminium Grip Cap 2 85 Nylon lock Nut M8 10

60 Aluminium Grip Ring 2 86 Nylon lock Nut M10 15

61 Button 19 87 ButtonΦ8.1*7 10

62 Connect Button 4 88 Hex Nut M10 1

63 Flat Philips Screw M5*25 2 89 Nut 2

64 Plastic Washer 4 90 Flat Head Cap Screw M8*20 6

65 Plastic Cover 4 91 Hex Key s=3 1

66 Self-Tapping Screw ST4.2*10 4 92 Hex Key s=4 1

67 Little Bumper 2 93 Hex Key s=5 1

68 Little Adjustable Ring 1 94 Hex Key s=6 1

69 Plug Φ32 2 95 Hex Key s=3/32" 1

70 Hex Head Bolt M10*100 4 96 Wrench 1

71 Hex Head Bolt M10*90 4 97 Lube 1

73 Hex Head Bolt M10*50 11 98 6" Pulley 2

74 Socket Head Cap Screw M8*20 2 99 Rivet Nut M8 2

75 Hex Head Bolt M10*25 6 100 Rubber Plug Φ29*Φ19*10 2

76 Socket Head Cap Screw M4*15 2 101 Hex Head Bolt M8*30 2

77 Button Head Cap Screw M8*20 1 102 Spring Washer Φ8 2

78 Button Head Cap Screw M6*12 12 103 Flat Washer Φ9*Φ22*1.6 2

79 Flat Head Cap Screw M10*30 11 104 Shroud Retainer Plate 2

80 Flat Philips Screw M5*16 11 105 Rear Support 1

81 Flat Washer Φ6.6*Φ18*1.6 12 106 Shroud 1

82 Flat Washer Φ11*Φ20*2 40 107 Short Shroud Retainer Plate 2

83 Flat Washer Φ9*Φ16*1.6 9 108 Top Rear Shroud 1
