1.7 Connectors
1.7.1 Rear panel connectors
1. PS/2 mouse port (green).ThisportisforaPS/2mouse.
2. Parallel port.This25-pinportconnectsaparallelprinter,ascanner,orotherdevices.
3. USB 3.0 ports.These9-pinUniversalSerialBus(USB)portsareforUSB3.0devices.
• DONOTconnectakeyboard/mousetoanyUSB3.0portwheninstallingWindows
®
operating system.
• DuetoUSB3.0controllerlimitations,USB3.0devicescanonlybeusedundera
Windows
®
OSenvironmentandafterUSB3.0driverinstallation.
• USB3.0devicescanonlybeusedfordatastorage.
• WestronglyrecommendthatyouconnectUSB3.0devicestoUSB3.0portsforfaster
andbetterperformancefromyourUSB3.0devices.
4. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoaLocalAreaNetwork(LAN)
through a network hub.
LAN port LED indications
LAN port
Speed
LED
Activity Link
LED
Activity/Link LED Speed LED
Status Description Status Description
Off Nolink OFF 10Mbpsconnection
Orange Linked ORANGE 100Mbpsconnection
Orange(Blinking) Dataactivity GREEN 1Gbps connection
Orange(Blinking
thensteady)
Readytowakeup
from S5 mode
5 643
78
2
11 10 9
1
12
ASUS H81M-V3
1-13
